Description
The VPX339 is based on the Data Device Corporation (DDC), BU-67118 multi-channel, multi-protocol avionics product. It utilizes the world’s most advanced MIL-STD-1553 technology. The module is low power, high MTBF, and high performance.
The module can output MIL-STD-1553A/B, IRIG106, ARINC 429, CAN bus/ARINC 825 channels, discrete I/O, ARINC-717, etc.
The module has an onboard DMA engine for low CPU utilization. IRIG-106 Chapter 10, Tx inhibit, and ARINC 717 which are ideal for flight data recorders.
The module is ideal for applications such as mission-computers, displays and LRUs, digital data recorders, radar systems/situational awareness, commercial aerospace, flyable avionics/UAVs, data loading and data monitors.
Features of VPX339 are:
- Up to 4 Dual Redundant Mil-STD-1553 channels
- Supports MIL-STD-1553A/B and MIL-STD-1760
- BC disable for RT only applications
- Tx Inhibit for MT only applications
- IRIG-106 Chapter 10 MIL-STD-1553 MT
- Up to 20 Programmable Tx/Rx ARINC 429 channels
- Support ARINC 575 and many other ARINC protocols
- Full line rate on all channels simultaneously
- Tx inhibit for ARINC 429 Rx only applications
- Programmable ARINC 429 speed
- Up to 2 Programmable Tx/Rx ARINC 717 channels
- Up to 2 CAN bus 2.0/ARINC 825 channels
- Up to 8 programmable RS-232/422/485 channels
- Asynchronous communications on all channels
- Synchronous communication on up to 2 channels
- Up to 10 Avionics/Digital discrete I/O
- 48-bit/100 ns Time Stamp
- IRIG-B Input
